BLS3837MED 37KG BLS Servo
●Suggested Retail Price: US$59.60
●Size: 40x20x38.00mm
●Weight: 80g(without servo horn)
●Gear: Steel Gears
●Operating speed:
0.10sec/60° @6.0V
0.08sec/60° @7.4V
0.07sec/60° @8.4V
Stall torque:
26.0kg-cm/361 oz-in @6.0V
31.0kg-cm/ 430 oz-in @7.4V
37.0kg-cm/ 514 oz-in @8.4V
●Motor Type: Brushless Motor
●Signal Type: Digital Control
●Case Material: CNC AL6061 Aluminum Case
●Connector Wire Length: 300MM JR Plug
BLS3848MED 48KG BLS Servo
●Suggested Retail Price: US$63.85
●Size: 40x20x38.00mm
●Weight: 80g(without servo horn)
●Gear: Steel Gears
●Operating speed:
0.13sec/60° @6.0V
0.10sec/60° @7.4V
0.09sec/60° @8.4V
●Stall torque:
36.0kg-cm/500 oz-in @6.0V
42.0kg-cm/ 583 oz-in @7.4V
48.0kg-cm/ 666 oz-in @8.4V
●Motor Type: Brushless Motor
●Signal Type: Digital Control
●Case Material: CNC AL6061 Aluminum Case
●Connector Wire Length: 300MM JR Plug
FH-2162 Micro Servo
●Motor: coreless motor
●Working frequence: 1520μs / 330hz
●Operating Voltage: DC6.0~7.4 V
●Operating Temperature Range: -10 to + 60°c
●Operating Speed (6.0V): 0.07sec/60 °
●Operating Speed (7.4V): 0.05sec/60°
●Stall Torque (6.0V): 4.8kg.cm (67.09oz/in)
●Stall Torque (7.4V): 6.2kg.cm (86.81oz/in)
●Potentiometer Drive: Direct Drive
●Dimensions: 23X12X27.6 mm
●Weight: 20.3 g (0.72oz)
BLS3858MED 58KG BLS Servo
●Suggested Retail Price: US$72.00
●Size: 40x20x38.00mm
●Weight: 80g(without servo horn)
●Gear: Steel Gears
●Operating speed:
0.17sec/60° @6.0V
0.14sec/60° @7.4V
0.12sec/60° @8.4V
●Stall torque:
42.0kg-cm/583 oz-in @6.0V
49.0kg-cm/ 680 oz-in @7.4V
58.0kg-cm/ 805 oz-in @8.4V
●Motor Type: Brushless Motor
●Signal Type: Digital Control
●Case Material: CNC AL6061 Aluminum Case
●Connector Wire Length: 300MM JR Plug
FH-2142 Micro Servo
●Operating Voltage: DC4.8-6.0 V
●Operating Temperature Range: -10 to + 60°
●Operating Speed (4.8V): 0.09sec/60°
●Operating Speed (6V): 0.08 sec/60°
●Stall Torque (4.8V): 3.2kg.cm
●Stall Torque (6V): 4.2kg.cm
●Potentiometer Drive: Direct Drive
●Dimensions: 23X12X27.6 mm
●Weight: 20.3 g (0.72oz)
CLS3838MED 38KG CLS Servo
●Suggested Retail Price: US$48.59
●Size: 40x20x38.00mm
●Weight: 78.8g(without servo horn)
●Gear: Steel Gears
●Operating speed:
0.12sec/60° @6.0V
0.10sec/60° @7.4V
0.09sec/60° @8.4V
●Stall torque:
29.0kg-cm/403 oz-in @6.0V
34.0kg-cm/ 472 oz-in @7.4V
38.0kg-cm/ 528 oz-in @8.4V
●Motor Type: Coreless Motor
●Signal Type: Digital Control
●Case Material: CNC AL6061 Aluminum Case
●Connector Wire Length: 300MM JR Plug
