Arthur Series Motor
Arthur Series is a manufacturer who specializing in the producing and marketing of racing motor.
Arthur Series Motor material as below:
Bearing: Imported NMB bearing
Iron Core: imported 0.2 silicon steel sheet
Motor Case: CNC processing
Shaft: Stainless Steel
Magnet: Arc-N52H
Our factory is equipped with 8 Motor Winding Machines, 3 Dynamic balancing machines, 6 Internal resistance device, 5 Multi-function tester, Flash Hobby has become a long-term and stable cooperative partner for many retailers.
Products
- View as
A5020 Brushless Motor
A5020 Brushless Motor
●Weight: 383.65g (including the cables)
●Motor Size: 57.5x45.2mm
●Shaft Diameter: 6.0mm
●Motor Mount: 25*25mm(4-M4)
●Configuration: 12N14P
●Motor Cable: 16AWG-600MM
●KV Value: 230KV or customed KV
A4130 Brushless Motor
A4130 Brushless Motor
●Weight: 374.59g (including the cables)
●Motor Size: 48.3x53.1mm
●Shaft Diameter: 6.0mm
●Motor Mount: 30*30mm(M4*4)
●Configuration: 12N14P
●Motor Cable: 16#AWG 600mm
●KV Value: 530KV or customed KV
A5220 Brushless Motor
A5220 Brushless Motor
●Weight: 412g (including the cables)
●Motor Size: 60.8X46mm
●Shaft Diameter: 6.0mm
●Motor Mount: 30*30mm(4-M4)
●Configuration: 12N14P
●Motor Cable: 16AWG-600MM
●KV Value: 350KV and 500KV or customed KV
A4720 Brushless Motor
A4720 Brushless Motor
●Weight (Incl.cable): 368.8g
●Motor Dimension: ф55.5 x 44.7mm
●Shaft Diameter: 6.0mm
●Motor Mount: 30*30mm(M4*4)
●Motor Mount Dia.: 4-M4*12
●Configuration: 12N/14P
●Motor Wire: Silicone 16AWG-600mm
●KV Value: 430KV, or customed KV
A4320 350KV Brushless Motor
A4320 Brushless Motor
●Weight: 318g (including the cables)
●Motor Size: 50.5 x 43mm
●Shaft Diameter: 6.0mm
*can be 5 or 6mm as per clients request
●Motor Mount: 30*30mm(M4*4)
●Configuration: 12N14P
●Motor Cable: 16#AWG 600mm
●KV Value: 350KV or customed KV
●Rated power: 432W
A4320 650KV Brushless Motor
A4320 Brushless Motor
●Weight: 323.09g (including the cables)
●Motor Size: 51.1 x 43.7mm
●Shaft Diameter: 6.0mm
*can be 5 or 6mm as per clients request
●Motor Mount: 30*30mm(M4*4)
●Configuration: 12N14P
●Motor Cable: 16#AWG 600mm
●KV Value: 650KV or customed KV
Arthur Series Motor is produced by our factory. As the manufacturer and supplier in China, we offer advanced Arthur Series Motor in high quality for wholesalers. If you want to buy, contact us for price list and we will send you quotation.
