ESC

Flash Hobby is a manufacturer who specializing in the producing and marketing of ESC.

An electronic speed control follows a speed reference signal (derived from a throttle lever, joystick, or other manual input) and varies the switching rate of a network of field effect transistors (FETs) . By adjusting the duty cycle or switching frequency of the transistors, the speed of the motor is changed. The rapid switching of the transistors is what causes the motor itself to emit its characteristic high-pitched whine, especially noticeable at lower speeds.

Different types of speed controls are required for brushed DC motors and brushless DC motors. A brushed motor can have its speed controlled by varying the voltage on its armature. (Industrially, motors with electromagnet field windings instead of permanent magnets can also have their speed controlled by adjusting the strength of the motor field current.) A brushless motor requires a different operating principle. The speed of the motor is varied by adjusting the timing of pulses of current delivered to the several windings of the motor.

Our factory is equipped with 8 Motor Winding Machines, 3 Dynamic balancing machines, 6 Internal resistance device, 5 Multi-function tester, Flash Hobby has become a long-term and stable cooperative partner for many retailers.
View as

F405 STACK CONTROLLER V2

F405 STACK CONTROLLER V2

F405 S●Item: F405 stack controller V2
●MCU:STM32F405
●IMU(Gyro): ICM42688
●USB Port Type: Type-C
●Weight: 7.5g
●Mounting Size: 30.5*30.5mm
●Dimension: 37(L) x 37(W) x 6.6(H)mm
 FLASH HOBBY BLS 50A 30.5x30.5 4-in-1 ESC
●Firmware: BLS 16.7
●Weight: 12g
●Dimension:42.3(L) * 37(W) * 6.2mm(H)
●Mounting Size:30.5 x 30.5mm( 4mm hole diameter)
●ESC Protocol: DSHOT300/600
tack

Read MoreSend Inquiry
F722 Stack Controller

F722 Stack Controller

●Item: F722 stack controller ●MCU:STM32F722RET6 ●IMU(Gyro): ICM42688 ●USB Port Type: Type-C ●Weight: 7.5g ●Mounting Size: 30.5*30.5mm ●Dimension: 37(L) x 37(W) x 6.6(H)mm  FLASH HOBBY BLS 60A 30.5x30.5 4-in-1 ESC ●Firmware: BLS 16.7 ●Weight: 12g ●Dimension:42.3(L) * 37(W) * 6.2mm(H) ●Mounting Size:30.5 x 30.5mm( 4mm hole diameter) ●ESC Protocol: DSHOT300/600

Read MoreSend Inquiry
Spaceman 20A

Spaceman 20A

Flash Hobby is one of the famous China Spaceman 20A manufacturers and suppliers. Our factory specializes in manufacturing of Spaceman 20A.
●Item: 30020
●Weight: 28.2g
●Size: 46*26*11
●BEC Mode: N/A
●BEC: 5V/2A
●BEC Output Capability: 4 servos(2-4S)
●Continuous:20A
●Burst(≤10s):25A
●Refresh rate of the throttle signal: 50Hz to 432Hz

Read MoreSend Inquiry
F405 STACK CONTROLLER

F405 STACK CONTROLLER

●Item: F405 stack controller
●MCU:STM32F405
●IMU(Gyro): ICM42688
●USB Port Type: Type-C
●Weight: 7.5g
●Mounting Size: 30.5*30.5mm
●Dimension: 37(L) x 37(W) x 6.6(H)mm
 FLASH HOBBY BLS 60A 30.5x30.5 4-in-1 ESC
●Firmware: BLS 16.7
●Weight: 12g
●Dimension:42.3(L) * 37(W) * 6.2mm(H)
●Mounting Size:30.5 x 30.5mm( 4mm hole diameter)
●ESC Protocol: DSHOT300/600

Read MoreSend Inquiry
Spaceman 30A

Spaceman 30A

You can rest assured to buy customized Spaceman 30A from Flash Hobby. We look forward to cooperating with you, if you want to know more, you can consult us now, we will reply to you in time!
●Item: 30030
●Weight: 28.6g
●Size: 46*26*11
●BEC Mode: N/A
●BEC: 5V/2A
●BEC Output Capability: 4 servos(2-4S)
●Continuous:30A
●Burst(≤10s):35A
●Refresh rate of the throttle signal: 50Hz to 432Hz

Read MoreSend Inquiry
Spaceman 10A

Spaceman 10A

The following is an introduction to Spaceman 10A, I hope to help you better understand Spaceman 10A. Welcome new and old customers to continue to cooperate with Flash Hobby to create a better future together!
●Item: 30010
●Weight: 14.8
●Size: 34*24*8mm
●BEC Mode: N/A
●BEC: 5V/2A
●BEC Output Capability: 4 servos(2-4S)
●Continuous:10A
●Burst(≤10s):12A
●Refresh rate of the throttle signal: 50Hz to 432Hz

Read MoreSend Inquiry
ESC is produced by our factory. As the manufacturer and supplier in China, we offer advanced ESC in high quality for wholesalers. If you want to buy, contact us for price list and we will send you quotation.
