K2303 Brushless Motor

K2303 Brushless Motor
●Weight: 18.5g (including the cables)
●Motor Size:28.5 x 13.6mm
●Shaft Diameter: 3.0mm
●Prop Mount Dia.: 4-M2*5
●Motor Mount: 12*12mm(M2*4)
●Configuration: 12N14P
●Motor Cable: 24#AWG 150mm

Model:K2303

Send Inquiry

Product Description

K2303-1750KV Motor Specification

Max pull：845g

Volts：23.9V(6S)

Suggested ESC: 20A~30A

Maximum Power：360.9W

Maximum Current: 15.10A

Suggested Prop: 5 inch prop

ltem NO.	Prop	Throttle	Volts (V)	Amps (A)	Watts (W)	Thrust (g)	Efficiency (g/W)	Operating temperature(℃)
K2303-1750KV	4023	50%	24.3	1.8	43.7	162	3.70	41℃
		60%	24.2	2.5	60.5	207	3.42
		70%	24.2	3.8	92.0	292	3.18
		80%	24.2	5.5	133.1	386	2.90
		90%	24.1	6.8	163.9	451	2.75
		100%	24	9	216.0	539	2.50
K2303-1750KV	5125	50%	24.3	3	72.9	279	3.83	70.7℃
		60%	24.2	4.3	104.1	362	3.48
		70%	24.2	6.4	154.9	498	3.22
		80%	24.1	8.3	200.0	616	3.08
		90%	24.0	11.4	273.6	758	2.77
		100%	23.9	15.1	360.9	845	2.34
