Control System(控制系统) | 1520us Pulse Width Modulation Control | |
Operation Voltage Range(工作电压) | 3.7V ~ 4.2V | |
Operation Temperature Range(工作温度) | -10C°~ +50C° | |
Circle(寿命) | 6000 times | |
Operation Travel(操作角度) | 90°± 10° | |
Limit angle (极限角度) | 180°± 10° | |
Direction(信号脉宽范围) | Re-clock wise/ Pulse Travel 900→2100 μsec | |
Diver type(马达驱动) | IC Drive | |
Motor Type(马达类型) | Coreless | |
Potentiometer Type(电位器处理方式) | Potentiometer | |
Amplifier Type(信号处理方式) | Digital Control | |
Dimensions(规格) | 13.5*6.2*16.0mm | |
Weight:(重量) | 1.7±0.1gg (without servo horn) | |
Test Voltage:(测试电压) | At 3.7V | At 4.2V |
Standing Torque(最大扭力) | 65g-cm | 75g-cm |
Speed(空载转速) | 0.07±0.01 sec/60° | 0.05±0.01 sec/60° |
Idle Current(空载电流) | 90±20mA | 100±20mA |
Running Current(负载电流) | 240±30mA | 310±30mA |
Dead band width(死区) | 5 usec | 5 usec |
Ball Bearing(轴承) | no | |
Gear Material(齿轮材料) | Plastic gears | |
Case Material(舵机外壳材料) | Nylon plus fiber | |
Connector Wire Length(线长) | 110mm JR | |
Connector Wire Gauge(线材型号) | OD0.6/PVC | |
Wire Info (Brown) | Negative | |
Wire Info (Red) | Positive | |
Wire Info (Yellow) | S Single |
