CLS4050RP 50KG CLS Servo

CLS4050RP 50KG CLS Servo
●Suggested Retail Price: US$45.99
●Size: 40x20x40.50mm
●Weight: 80g±10g(without servo horn)
●Gear: Steel Gears
●Operating speed: 0.15sec/60° @6.0V
0.12sec/60° @7.4V
0.11sec/60° @8.4V
Stall torque: 38.0kg-cm/527 oz-in @6.0V
45.0kg-cm/ 625 oz-in @7.4V
50.0kg-cm/694 oz-in @8.4V
●Motor Type: Coreless Motor
●Signal Type: Digital Control
●Case Material: CNC AL6061 Aluminum Case
●Connector Wire Length: 300MM JR Plug

Model:CLS4050RP

Send Inquiry

Product Description

CLS4050RP 8.4V 50KG Super Torque 0.11 SPEED Programmable Servo Coreless Motor compatible with Sanwa SSR, NB4 and Futaba mode


CLS4050RP 50KG CLS Servo FEATURE:
●Programmable PWM Digital Amplifier
●32-Bit MCU
●High Precision Gear
●Wide Operating Voltage (6.0 ~ 8.4 Volts DC)
●Dual Ball Bearing Supported Output Shaft
●25-Tooth Output Spline
●High Quality Coreless Motor
●Diamond Cut Aluminum Heat Sink Shell
●Water Resistant and Waterproof Case
●Mode Compatible Sanwa SSR, NB4 and Futaba mode

Helica gears will be with small false space, high bite, low noise and hgiht smoothness

Programmable Functions
●End Point Adjustments
●Direction
●Fail Safe
●Dead Band
●Speed (Slower)
●Soft Start Rate
●Overload Protection
●Data Save / Load
●Program Reset
