CF2822 Fixed Wing Motor

Weight: 50g
Motor Size: 28.5*20.5mm
Shaft Size: 3.17*48mm
Motor Mount: 22mm(M3*4)
Working Temperature Range:-0℃~+80℃
Control Method:Use ESC to Adjust PWM signal for Control,PWM Adjustment Range 900- 2100US
Motor Type: Outrunner Brushless Motor,Three-phase Motor
KV Value: 1534KV, 1200KV, 2840KV or customed KV

Send Inquiry

Product Description

CF2822-12-1534KV Motor Specification

Max pull900g

VoltsDC7.4~16.80V

Suggested ESC: 10A~30A

Maximum Power206W

Suggested Prop: 6 inch prop


CF2822-14-1200KV Motor Specification

Max pull830g

VoltsDC7.4~16.8 V

Maximum Power200W

Suggested Prop: 6~7 inch prop


CF2822-16-2840KV Motor Specification

Max pull200g

VoltsDC7.4~16.8 V

Maximum Power128W

Suggested Prop: 6~7 inch prop



MOTOR Drawing:









Product Details:







Application:


Connected instructions



Packed(With Accessory)

Flash Hobby motor *1, M2X7 Screw X 4, plastic Ring*1, Prop-Saver*1



FAQ

1What is the MOQ of the regular item?

A: There isnt MOQ limited for the stock item. But if need to change the color or design, we will set up the MOQ as per the different request.

2If the order quantity is large, if can apply the discount from dealer price?

A: Yes, we will offer our best offer as per the different request.

3If need change anything when the order confirmed, pls how we can do?

A: If you have request, pls contact with us within 2 days when the order was confirmed, otherwise, it cant be cancelled or change any design of motor.

4How long the delivery time?

A: It is about 7 days when the order is confirmed for the regular item.

5What is the leadtime of OEM/OMD order?

A: Normally it is 15-30 days.

6、What is the MOQ of OEM/OMD order?

A: Single color Motor MOQ-200PCS;

    Multi-color Motor MOQ-1000PCS
